| Description |
| 13.09.13 Specification: Low compression block but raised compression from 9.4:1 to 10.2:1 (near enough high comp block CR) Engine: Cat Cams 252/260 – 8.5mm / 9.0mm Lift Camshafts Blox Adjustable Vernier Pulleys Cometic 0.040” Thick, 82mm Bore Metal Head Gasket 81.5mm Oversize Pistons & Rings ARP Main Studs ARP Rod Bolts New Mahle Main Bearings New Mahle Crankshaft thrust Bearings New Mahle Conrod Bearings New Water Pump New Sump & Bolt Kit Brakes: ST165 GT4 Twin Pot Calipers Red Stuff Front Pads Mk3 Rear Calipers Yellow Stuff Rear Pads HEL Yellow Braided Lines Transmission: Fidanza Lightened Flywheel Corolla T-Sport Clutch & Pressure Plate Suspension: Koni SSK Suspension Kit Superflex Front & Rear ARB Bushes Mk2 Turbo 18mm Rear ARB Upgrade Tyres & Wheels: Refurbed Mk3 Roadster Alloys in Sparkle Silver 195/50/15 VR rated Yoko Parada Spec 2 on Front 195/50/15 VR rated Uniroyal Rainsport 2 on Rear MOT passed second time around due to adjusting TPS and timing. 13.06.14 (Friday 13th) Cambelt snapped. Original thoughts were dodgy belt, but it has come to light that a bolt I left loose, dropped into the cambelt covers and chewed up the belt, damaged the timing belt cog and damaged the guide plate, resulting in a shredded belt that lasted 1300 miles. No damage to crank/pistons/valves that I'm aware of. 16.03.15 Finally in the last few months I've found the time to strip the bottom down to the oil pump which I've replaced as I also had low oil pressure. Rear hubs have been replaced as well. Driveshafts will be replaced as well to cure rear end wobble. New cambelt will be fitted at the end of March. |
